SMB ENUMERATION


SMB  ENUMERATION

DESCRIPTION
There are multiple ways available these days to enumerate SMB. Various tools (OpenSource and Commercial) can make your enumeration task more easier.

In the field of information security, every little information count and while penetration testing if you found port 139 open, either externally or internally then there are more chances of information leakage through SMB service. Lets check it out what information we are talking about and how much these information helps us to take our penetration testing to the next level.

At the time writing this article, my lab setup look like this:

Target Machine: Running Stapler (Vulnerable Machine) with 139 port open.
IP Address: 192.168.1.105

Attacker Machine: Running Kali Linux (With my arsenal :)

IP Address: 192.168.1.111
Attacker Machine (Kali Linux)

Note: Here everything is running on VMware environment, just for educational purpose only. If you try this on someone other network take it at your risk.

Now lets directly come to point of enumerating port 139 (SMB). But before that,we gonna check for banners, as-usual revealing a lot information for us. Lets go.

TCP SCAN
TCP PORT SCAN
UDP SCAN
UDP PORT SCAN
NOTE
Before going more deeper, it's very important to understand  services we are targeting i.e NETBIOS. So according to wikipedia NETBIOS provides three distict services:
  1. Session service (NetBIOS-SSN) for connection-oriented communication.
  2. Name Service (NETBIOS-NS) for name registration and resolution.
  3. Datagram distribution service (NetBIOS-DGM) for connectionless communication.
From above three services, we only going to focus on first two of them i.e NetBIOS-SSN & NETBIOS-NS.

Session service (NetBIOS-SSN)
  • Session mode lets two computers establish a connection, allows messages to span multiple packets, and provides error detection and recovery. In NBT (Netbios over TCP/IP), the session service runs on TCP port 139. ~Wikipedia
Name Service (NetBIOS-NS)
  • In order to start sessions or distribute datagrams, an application must register its NetBIOS name using the name service.
  • NetBIOS names are 16 octets in length and vary based on the particular implementation.
  • The name service operates on UDP port 137 (TCP port 137 can also be used, but rarely is). ~Wikipedia
SAMBA
  • Samba is a free software re-implementation of the SMB/CIFS networking protocol, and was originally developed by Andrew Tridgell.
  • Samba provides file and print services.
  • Samba runs on most Unix, OpenVMS and Unix-like systems, such as Linux, Solaris, AIX and the BSD variants, including Apple's OS X Server, and OS X client (version 10.2 and greater).
  • The name Samba comes from SMB (Server Message Block), the name of the standard protocol used by the Microsoft Windows network file system. ~Wikipedia
NMAP SHARES SCAN
Resouces: https://nmap.org/nsedoc/scripts/smb-enum-shares.html
Open the below image in a new windows and try to figure it out what information you got. Nmap script is the good way to start SMB Enumeration.

AT UDP

ENUM4LINUX
It is a tool for enumerating information for Windows and Samba systems. It is written in perl and already installed on kali linux.
KEY FEATURES
RID cycling, User listing, Listing of group membership information, Share enumeration, Detecting host is in workgroup or domain, Identifying the remote operating system, Password Policy retrieval etc. Lets Enumerate SMB with Enum4linux

Help Command: enum4linux -h


Verbose Mode
Command: enum4linux 192.168.1.105

Retrieve a List of Usernames via RID Cycling (RestrictAnonymous = 1)
To retrieve the usernames corresponding to a default range of RIDs (500-550,1000-1050) use the -r option:

Retrieve a List of Usernames by specifying RID range with -R option:

Retrieve Netbios Information
The -n option causes enum4linux to run nmblookup and does some extra parsing on it’s output to provide human-readable information about the remote host.

Listing Windows Shares
If the server allows it, you can obtain a complete list of shares with the -S option. This uses smbclient under the hood which also seems to grab the browse list.


Listing Windows Shares with Verbose Mode


The below image helps you to understand smbclient is used to mapping the shares. See the below image for more details:


Retrieving OS Information

Retrieving Printer Info
You can get some information about printers known to the remote device with the -i option.

AT THE END
  • We enumerate SMB by using Nmap and Enum4linux.
  • Enum4linux automates our SMB enumeration and helps us to take our penetration testing to next level.
  • I hope this article on "SMB Enumeration" helps someone in infosec community. Signing off :)
  • Join us on Facebook - https://www.facebook.com/hackingDNA
Resources

          THIS IS JUST FOR EDUCATIONAL PURPOSE ONLY/-
